Leica DISTO™ transfer
Using the CAD Plugin for Autocad® and Bricscad
1. To start the Plugin for Autocad® and Bricscad you have to start the
corresponding CAD software and write the command „leicadisto“ in
the command field. If Leica DISTO™ transfer is not already open it will
be opened now automatically.
2. Click in the drawing area and start transfering distances. If you
transfer distance and inclination the horizontal distance will be
calculated and used in drawings.
3. If the inclination is more than 75° it will be interpreted as a vertical
distance and used as a height. Only one height can be entered per
layout (change to 3D view to see the three dimensional drawing).
4. The arrow keys on the Leica DISTO™ (press 2nd for usage) can be
used to select drawing direction.
