DYNON AVIONICS

Servo Mounting Instructions – RV-7/8/10 Roll Kit

2

101046-003 Rev G


SERVO MOUNTING INSTRUCTIONS – RV-7/8/10 RIGHT WING

ROLL KIT

Kit Contents

Dynon Part # QTY Part Description

100836-000

2

Large Male Rod End

100870-001

1

RV7,8,9,10 Right Roll Bracket

100872-000

1

RV7,8,9,10 Right Support Bracket

100966-008

1

Aluminum Pushrod Tube - 3.0"

100975-002

2

AN315-4R Jam Nut

100976-011

2

AN365-1032A Nylon Insert Locknut

100977-000

2

AN970-3 Large Flat Washer

100978-003

7

AN960-10 Small Flat Washer

100979-002

3

MS35333-39 #10 Internal Star Washer

100981-000

3

AN3H-3A Bolt - 3/8"

100981-005

1

AN3H-10A Bolt - 1"

100981-012

1

AN3H-17A Bolt - 1 7/8"

100982-004

1

Aluminum Spacer - 0.875"


The RV-7/8/10 right wing roll servo mounting kit includes a right wing mounting bracket, right

wing support bracket, pushrod linkage, and most of the required fasteners to mount the servo and
properly link it to the aircraft control system. All Dynon-supplied parts are illustrated in dark grey to

distinguish them from existing aircraft hardware. The lower bell crank support bracket must be
removed to install the supplied servo mounting bracket. Fasteners used to secure the existing

brackets will be re-used to install the new Dynon brackets. It is up to the installer to determine if
these fasteners are suitable for re-use (not available from Dynon). With the mounting brackets

loosened/removed it is an ideal time to drill the aileron bell crank bracket per the dimensions in the
illustration.
The brackets that will replace the existing aircraft brackets are made of 4130 steel and plated per
QQP416 CAD - Type II Class II Yellow. They have been designed to meet or exceed the original

brackets in strength and corrosion resistance. Install the Dynon-supplied lower servo mounting
bracket in place with the previously removed original fasteners and install the vertical bolt as it was

in the original installation.
With the bracket in place, install the 2 AN3H-3A bolts, MS35333-39 star washers, and AN960-10

flat washers to secure the servo to the bracket per the drawing, noting the orientation of the servo
output arm. All AN bolts supplied by Dynon have drilled heads for use with safety wire.
