DYNON AVIONICS
Servo Mounting Instructions – Sonex/Waiex Roll Kit 3
101866-000 Rev A
SERVO INSTALLATION AND CONFIGURATION
The Sonex/Waiex roll servo mounting kit includes a servo mounting bracket, fuselage floor
doubler, connecting hardware, and push rod required to complete the installation of the Dynon
SV-42EL servo into a dual control Sonex/Waiex aircraft. All Dynon-supplied parts are shaded to
distinguish them from existing aircraft hardware and structure. If the builder is attempting to
install the servo in an aircraft configuration other than that shown, modifications to the kit may
be required.
SUGGESTED INSTALLATION PROCEDURE
INVENTORY
PARTS
ASSEMBLE
PUSHROD
ATTACH PUSHROD
TO PILOT SIDE
CONTROL STICK
HORN AND
LINK ROD
INSTALL SERVO
FLOOR PLATE
INSTALL SERVO IN
MOUNTING BRACKET
ATTACH SERVO
TO PUSHROD
POSITION SERVO
ON FLOOR PLATE
DO YOU HAVE FULL
AND UNOBSTRUCTED
MOVEMENT?
INSTALL SERVO
MOUNTING BRACKET
TO FLOOR PLATE
SERVO
CALIBRATION
NO
YES
Read Instructions
Complete
