Sangean ATS-909 w (V1) User Manual

Page 5

18
19

ROTARY
TUNING
KNOB

TIME SET

ENTER SELECTION/0 Secretary. TIME SET

SELECTION CANCE/11 M SELECT

DIGIT INPUT/CLOCK/MEMORY & SW BAND

DECIMAL POIN/SW 15 METER BAND

METER/SW SELECTS SW BAND

ATS/MW

SELECTS MW BAND/PRESETS ALL STATIONS

SELECTS FM BAND/PRESETS ALL STATIONS

ATS/LW

ATS/FM

SELECTS LW BAND/PRESETS ALL STATIONS

AM RF GAIN

ADJUSTS LEVEL OF INCOMING SIGNAL TO

PREVENT OVERLOAD AND DISTORTION

AM EXT ANT JACK FOR EXTERNAL AM ANTENNA

REC/STAN
BY

TURN-ON FOR EXTERNAL RECORDER

REC/LINE
OUT

AUDIO OUTPUT

HEADPHONE JACK

DC IN 6VDC

JACK FOR EXTERNAL 6VDC POWER ADAPTER

EDIT CHARACTERS SELECTED/FREQUENCY
ADJUSTMENT, HOME-WORLD CITY SELECTION, SW PAGE SELECTION

SELECTS AUTO OR MANUAL MODE FOR TIME SET

WIDE
NARROW

VOLUME

TONE

MW STEP

TELESCOPING ANTENNA

LCD DISPLAY

BATTERY COMPARTMENT

FOLDING STAND

D I S P L AY I C O N S

a . H O M E / W O R L D T I M E
b . D AY L I G H T S AV I N G S T I M E
c . T I M E

AM WIDE/NARROW FILTER/FM MONO STEREO
SELECTOR

ADJUSTS VOLUME LEVEL

TONE CONTROL (NEWS, MUSIC, NORMAL)

US/FOREIGN STATION FREQ. SPACING, (9KHz/10KHz)
