Auxiliary input socket
A 3.5mm stereo Auxiliary Input socket is provided on the left hand
side of your radio to permit an audio signal to be fed into the unit
from an external audio device such as iPod, MP3 or CD player.
. Repeatedly press and release the Band button until AUX IN is
shown.
2. Connect an external audio source (for example, iPod, MP3 or
CD player) to the Auxiliary Input socket.
3. Adjust the volume setting on your iPod, MP3 or CD player to
ensure an adequate signal level from the player, and then rotate
the Volume control on the radio as needed for comfortable listening.
Headphone socket
A 3.5mm Headphone socket located on the left hand side of
your radio is provided for use with headphones. Inserting a plug
automatically mutes the internal loudspeaker.
Note:
You cannot hear the sound with mono earphones. This unit can
only work with stereo earphones.
IMPORTANT:
Excessive sound pressure from earphones and headphones can
cause hearing loss.
