Controls, Lcd display – Sangean H201 (R1) User Manual
Page 4
3
GB
LCD Display
Preset stations (preset 3 also for tuning step change)
Nap timer (Short timer)
Power button
Band and Time Set button
Tuning Control
Volume Control
Speaker
DC IN socket
Hanger Ring
Emergency Buzzer
Torch button
Torch
Multi Purpose Handle
Bracket Holder
Battery Cover
FM wire antenna compartment
Controls
2
3
4
5
7
5
4
3
2
0
9
6
8
7
6
LCD Display
Battery Power Status
Volume level
Auto Off status
Short Timer set
Memory number and seconds
Time and Frequency
Band indicator
G
F
E
D
C
B
A
