Controls – Sangean WR-15 (V1) User Manual
Page 7
6
GB
Controls
AM/FM/Aux in/Bluetooth band selecting rotary (Bluetooth band
is only available in WR-15BT)
Tuning LED indicator
Dial indicator
Dial scale
Tuning Control
Volume control/Power knob
Speaker
F-type external antenna terminal
WR-5: AM external antenna terminal
WR-5BT: Bluetooth status indicator
VDC socket
Headphone socket
Line out socket
Aux in socket
External/Internal antenna switch
NFC detection area (WR-15BT only)
5
3
4
5
7
9
0
3
4
8
6
