HXJZ-875

Low Power

Wireless

Module

User’s Manual

Technical specification of HXJZ-875

Modulation mode:

GFSK

Working frequency:

433MHZ

Transmission power:

2W/1W

Receiving sensitivity:

-123dBm

Transmitting current::

<1.5A

Receiving current:

<50mA

Channel speed rate:

1200/2400/4800/9600/19200/38400Bit/s, User can Choose one

Interface speed rate:

1200/2400/4800/9600/19200/38400Bit/s, User can Choose one

Change time for receiving and sending:

<20ms

Interface data format:

8E1/8N1/8O1

Power supply:

0.5V DC

Working temperature:

-40℃~85℃

Working humidity:

10%~90% relative humidity without condensation

Dimension:

85mm*54mm*20 mm

Attachable Communication with Model: JZ871/JZ872/JZ873/HXJZ-875/JZ878

Model and name

JZ

875

-T

T: TTL interface

2: 232 interface

4: 485 interface

Products Item

Company logo

Optional Antenna:

Trouble and solve ways:
