HXJZ-874 Mini Power Wireless Module User’s Manual

About HXJZ-874

HXJZ-874, the mini power wireless module Enveloped with Epoxy, is used as the wireless data

transmission in short distance.

With the small size, weight and power consumption and good stability and reliability, it has the function

of bidirectional data sign transmission, test and control.

It is used for Wireless meter reading, such as Water Meter, Ammeter and Gas Meter, Parking Meter,

intellective card, electronic weighi ng apparatus, meter for checking on work attendance, queue wireless meter,

building control, shipping company control, alarm system, intelligent equipment, Automatic data collecting

system; Industrial remote control and remote test building automation, safety and security, powerhouse

equipment wireless monitor, entrance control system, etc.

If necessary, we can provide USB interface to make it easy to settle the question of Power Supply for

Mini computer and PC users.

HXJZ-874 Feature

1.

Ultra low power transmission

Transmission power: < 500mW(HXJZ-874B), < 100mW(HXJZ-874A);High receiving sensitivity:

-123dbm,

Size: 70mm*45mm*19mm

2. Low power consumption

Receiving current<45mA, transmission current<360mA( HXJZ-874B),. <100mA(HXJZ-874A),

3. ISM frequency band, not requiring on application of frequency point

Carrier frequency of 428 ---433MHz,also capable of 868/915MHz.

4. High anti-interference and low BER (Bit error Rate)

Based on the GFSK modulation mode, it adopts the efficient communication protocol. T he actual bit error

rate of 10-5 ~ 10-6 can be achieved when channel bit error rate is 10-2.

5.

Long transmission distance

Within the range of visibility, the reliable transmission distance is ( BER=10-3/1200bps )

>3000m(HXJZ-874B)

, >800m

(HXJZ-874A),when the antenna

height is greater than

3m

(BER=10-3/9600bps).

6.

Transparent data transmission

Transparent data interface is offered to suit any standard or nonstandard user protocol. Any false data

generated in the air can be filtrated automatically (What has been re ceived is exactly what has been

transmitted). The charge time for receiving and sending <10ms.

7.

Multi-channel and speed

The standard HXJZ-874 configuration provides 8 channels. to meet the multiple communication

combination mode of the users. It has baud rate to be chosen such as 1200bps 、2400bps、4800bps、9600bps、

19200bps、38400bps. The wireless transmission rate is direct ratio with baud rate of interface to meet user ’s

equipment requirement.
