HXJZ-864 Mini Power Wireless Module User’s Manual
Technical specification of HXJZ-864
Modulation mode: FSK
Working frequency: 428---433MHZ
Transmission power: ≤ 100mW
Receiving sensitivity: -110dBm
Transmitting current:: <100mA
Receiving current: <10mA
Channel speed rate: 1200/2400/4800/9600/19200Bit/sUser can choose
Interface speed rate: 1200/2400/4800/9600/19200Bit/s User can choose
Change time for receiving and sending: <10ms
Interface data format: 8E1/8N1/8O1
Power supply: 5±0.5V DC(power supply from USB interface)
Working temperature: -20℃～85℃
Working humidity: 10%～90% relative humidity without condensation
Dimension: 47mm *33mm * 14mm（not include antenna）
Attachable Communication with Model: JZ862/JZ863/HXJZ-864/JZ866.
Optional Antenna:
