HXJZ-863 Mini Power Wireless Module User’s Manual
Technical Specification OF HXJZ-863
Modulation mode: FSK
Working frequency: ---433MHZ
Transmission power: <100mW
Receiving sensitivity: -110dBm
Transmitting current: <100mA
Receiving current: <11mA
Sleeping current: <10uA
Channel speed rate: 1200/2400/4800/9600/19200Bit/ s Users can choose from
that. Interface speed rate: 1200/2400/4800/9600/19200Bit/ s Users can choose
from that. Change time for receiving and sending: <10ms
Interface data format: 8E1/8N1/8O1
Power supply: .8--3.6V or 3.6--5.5V (TTL)DC , 5± 0.5V (RS232/RS485),
Working temperature: -20℃～85℃
Working humidity: 10%～90% relative humidity without condensation
Dimension: mm*27mm*8mm (not include antenna)
Attachable Communication with Model: JZ862/HXJZ-863/JZ864/ JZ866
Model and name
JZ 863 -T
T：TTL interface
2：232 interface
4：485 interface
Nakedboardno
Company logo
