OFNA Racing Ultra LX 2e RTR - Manual (Page 39)

OFNA DESCRIPTIONS RETAIL OFNA DESCRIPTIONS RETAIL
16015 HI FORCE WING, 1/8 WHITE 15.95 34055 PINS, LOWER REAR ARMS 3x42.6mm 15.95
30010 GEARBOX, ULTRA SERIES 14.95 34063 FRONT & REAR LOWER ARMS 13.95
30082 CAP JOINTS, 6mm, 2 PCS. 9.95 36020 FRONT UPPER ARMS, 2 PCS. 5.95
30102 BODY MOUNT POSTS, 2 PCS. 0.95 36053 BEARING, 8x16mm, PAIR 12.95
30110 SPUR GEAR,(NYLON) ULTRA 7.95 36055 PIN, 2.5x17mm, HEX HUBS, 4PCS 3.95
30120 LARGE BEVEL GEAR,44T 10.95 36055 PIN, 2.5x17mm, HEX HUBS, 4PCS 3.95
30121 BEVEL MOUNTING HARDWARE,MISC 1.95 36081 REAR UP-RIGHT (8mm BEARING) PR 12.95
30130 PINION GEAR,14T ULTRA 14.95 36082 REAR AXLES, 8mm PAIR 10.95
30160 FRONT PLATE, ARM PIN HOLDERS 4.95 36100 CENTER DOGBONES,SET 86.5,90mm 16.95
30201 CENTER, DIFF MOUNT, NEW TYPE 13.95 36170 ARM PINS, 3mm 4PCS LX1 7.95
30240 FRONT BUMPER, ULTRA CHASSIS 7.95 36171 ARM PIN 4x74.1mm LX1 & X2T 5.95
30270 WING STAY,REAR,PLASTIC 13.95 36640 ARM SHAFT, 4mm, SHORT, 2PCS 9.95
30341 BALL END WITH COLLAR, 6mm 3.95 36700 STEERING BALL END, 7mm, 8PCS. 6.95
30351 REAR ARM HOLDER 3PCS 3.95 36741 SPRING, SERVO SAVER NEW HARD 3.95
30361 SERVO SAVER SHAFT 5.95 36742 BUSHING, SERVO SAVER 1.95
30380 SERVO SAVER POSTS, 2 PCS. 4.95 36743 E-CLIP, 6MM SERVO SAVER 2.95
30401 STEERING ENDS, PLASTIC 6 PCS. 2.95 36760 FRONT PLATE JOINT 9.95
30403 6mm BALL, STEEL (NO COLLAR) 4.95 36790 4x46MMTURNBUCKLES,4PCS. 10.95
30411 6mm BALLS w/COLLAR,STEERING 6P 4.95 36850 7mm BALL, 6 PCS. 3.95
30620 BEARING KIT, 7x19mm, 6 PCS. 29.95 36861 5x40mm TURNBUCKLES, 2 PCS BLK 6.95
30630 BEARING KIT, 6x13mm 12PCS. 59.95 37410 BODY CLIPS, 10 PCS. SMALL JL10 3.95
30649 SHOCK TOWER REAR LX1 H.C. 11.95 38280 TURNBUCKLES, 3X36MM 2PCS 5.95
30653 CENTER TOP PLATE LX1 H.C. 6.95 40038 BALLS, 7MM 4PCS. 9.95
30656 WHEEL HUB, LX1, PICCO 9.5 H.C. 11.95 40039 TAPPER CONE WASHERS,3MM 3.95
30657 LOWER ARM,FRONT, LX1 13.95 40053 SHOCK BODY REAR,THREADED,2PCS 59.95
30658 SERVO SAVER CONNECTOR H.C. LX1 6.95 40054 SHOCK SHAFTS,3.5m FR 13/16mm 7.95
30661 SERVO HORN HEAVY DUTY BLACK 4.95 40055 SHOCK SHAFTS,3.5m RR 13/16mm 7.95
30662 BATTERY CASE,RX BOX LX-1e 19.95 40058 SHOCK BOOTS,SILICON 9.95
30663 BATTERY VELCRO STRAPS LX-1e 9.95 40060 SHOCK PISTON LOCKNUT,2.5mm,4PC 4.95
30665 PINION 14T 5MM SHAFT 12.95 40065 BALL ENDS, PLASTIC, REAR UPPER 4.95
30673 FRONT ARM HOLDER,H.C. LX-1 12.95 40113 O-RING P-10 FOR X1-CR,9.5 SHCK 1.95
30674 SERVO SAVER PLASTIC SET LX-1 7.95 40199 BALL END,STEERING,PLASTIC,6mm 7.95
30675 MOTOR MOUNT,CNC, LX-1e 29.95 40520 KNUCKLE ARM, L & R LX-2 19.95
30676 CHASSIS H.C. LX-1e 89.95 40527 KNUCKLE ARM BUSHING LX-2 4.95
30686 CENTER BRACE LX-2 PLASTIC 9.95 40528 KING PIN SCREW LX-2,X1X,NEXX8 1.95
30693 SPEED CONTROL 90A LX2 RTR 219.95 40536 FRONT C HUB LX-2,X1X,X2,NEXX8 11.95
30694 BRUSHLESS MOTOR 1900KV 5MM SHT 119.95 40550 WHEEL NUT 17mm LX-2 4.95
30751 CASE, DIFF (K), FRONT or REAR 9.95 40642 ANTENNA , FIXING NUT 2.95
30761 CASE, DIFF CASE (K), CENTER 9.95 40643 PLASTIC SHOCK PARTS,13/16mmLX2 9.95
30769 DIFF GEAR,SILVER BEVEL,SET 4mm 14.95 41003 SHOCK BODY FRONT 16MM PAIR 29.95
30773 CROSS PIN AXLES, 4mm STEEL 3.95 41004 SHOCK BODY REAR 16MM PAIR 29.95
30776 WASHER, 4x10x0.2mm 4PCS. 1.95 41005 SHOCK CAP 16MM 4PCS. 22.95
30777 SEAL, O-RING DIFF CASE 3.95 41006 SHOCK SPRING ADJ. 16MM 4PCS. 14.95
30779 MISC. PARTS, ULTRA DIFF 9.95 41007 O-RING 19x1.5MM 16MM 4PCS. 4.95
30780 PINS, 2X12.8mm FOR DIF 2PCS 3.95 41008 PLASTIC SHOCK PARTS 16MM SET 12.95
30901 CAP JOINT W/SHAFT F/R DIFF 11.95 41009 CAP SCREWS 3X28MM 4PCS. 2.95
30911 CAP JOINT W/SHAFT, BRAKE 11.95 41010 SHOCK BALL END POST LONG 4PCS 11.95
31143 BODY, CLEAR ULTRA LX2e 39.95 41011 SHOCK PISTON 16MM 8PCS. 10.95
31158 BODY, LX2e PRINTED RTR 55.95 41012 REPAIR KIT FOR 16MM SHOCK 9.95
31159 BODY CLIPS, CHROME 4.95 41013 PRESSURE TOP ORANGE 16MM 4PCS. 7.95
34014 BRACE, FRONT CHASSIC,ULTRACOMP 3.95 41022 SPRING .58 REAR 16MM WHITE 9.95
34027 ANTI-ROLL BAR KIT, U.COMP,LX1 3.95 41033 STONE GUARDS X2T 15.95
34054 SHAFT, REAR DOG BONE 93mm PR. 15.95 80025 TIRES, TRIAD 1/8 BUGGY W/FOAM 24.95
86056 17mm TrueLITES DISH, WHT 6PACK 19.95
34301 ULTRA LX2e RTR PARTS LIST
