7 – English
FEATURES
PRODUCT SPECIFICATIONS
Chuck ...........................................................1/2 in. Keyless
Motor ......................................................................18 V DC
Switch .............................. VSR (Variable Speed Reversible) No Load Speed ....................... 0-440/0-1,600 r/min. (RPM)
Clutch .............................................................. 24 Positions
Torque ................................................................... 350 in.lb.
KNOW YOUR DRILL-DRIVER
See Figure 1, page 12.
The safe use of this product requires an understanding of
the information on the product and in this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all oper-
ating features and safety rules.
BIT STORAGE
The bit provided with the drill can be placed in one of the
storage areas located on the base of the drill.
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
Your drill has a direction of rotation (forward/reverse/center
lock) selector located above the switch trigger for changing
the direction of bit rotation. Setting the direction of rotation
selector in the
OFF (center lock) position helps reduce the
possibility of accidental starting when not in use.
KEYLESS CHUCK
The keyless chuck allows you to hand-tighten or release the
drill bit in the chuck jaws.
LED WORKLIGHT
The LED worklight, located on the front of the tool, illuminates
when the switch trigger is depressed. This provides extra
light for increased visibility.
LEVEL
A level is located on the top of the motor housing to help
keep the drill bit level during use.
MAG TRAY™ (SCREW HOLDER)
The magnetic tray conveniently stores screws or other small
parts.
TORQUE ADJUSTMENT RING
Your drill has a 24-position clutch. The torque adjustment
ring can be turned to select the right amount of torque for
your application.
TWO-SPEED GEAR TRAIN (HI-LO)
The two-speed gear train is designed for drilling or driving
at
LO (1) or HI (2) speeds. A slide switch is located on top
of your drill for selecting either LO (1) or HI (2) speed.
VARIABLE SPEED
The variable speed switch trigger delivers higher speed with
increased trigger pressure and lower speed with decreased
trigger pressure.
ASSEMBLY
UNPACKING
This product has been shipped completely assembled.

Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
WARNING:
Do not use this product if it is not completely assembled
or if any parts appear to be missing or damaged. Use of
a product that is not properly and completely assembled
could result in serious personal injury.
 Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
 Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
 If any parts are damaged or missing, please call
1-800-525-2579 for assistance.
PACKING LIST
Drill
Double-ended Bit
Operator’s Manual
