7 − English
OPERATION
WARNING:
Do not allow familiarity with tools to make you care-
less. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes resulting in possible
serious injury.
WARNING:
Do not use any attachments or accessories not recom-
mended by the manufacturer of this tool. The use of at-
tachments or accessories not recommended can result
in serious personal injury.
APPLICATIONS
You may use this tool for the purposes listed below:

Drilling in all types of wood products (lumber, plywood,
paneling, composition board, and hardwood)
 Drilling in ceramics, plastics, fiberglass, and laminates
 Drilling in metals
This product will accept Ryobi One+ 18 V lithium-ion battery
packs and Ryobi One+ 18 V nickel-cadmium battery packs.
For complete charging instructions, refer to the Operator’s
Manuals for your Ryobi One+ battery pack and charger
models.
BATTERY PROTECTION FEATURES
Ryobi lithium-ion batteries are designed with features that
protect the lithium-ion cells and maximize battery life.
If the tool stops during use, release the trigger to reset and
resume operation. If the tool still does not work, the battery
needs to be recharged.
TO INSTALL/REMOVE BATTERY PACK
See Figure 2, page 11.
WARNING:
Always remove battery pack from your tool when you are
assembling parts, making adjustments, cleaning, or when
not in use. Removing battery pack will prevent accidental
starting that could cause serious personal injury.
To install the battery pack:

Place the direction of rotation selector in center position.
 Align raised rib on battery pack with groove in drill’s bat-
tery port.
 Make sure the latches on each side of the battery pack
snap in place and that battery pack is secure before
beginning operation.
To remove the battery pack:

Place the direction of rotation selector in center position.
 Locate latches on side of battery pack and depress both
sides to release battery pack from the drill.
 Remove battery pack from the drill.
WARNING:
Battery tools are always in operating condition. There-
fore, switch should always be locked when not in use or
carrying at your side.
SWITCH TRIGGER
See Figure 3, page 11.
To turn the drill
ON, depress the switch trigger. To turn it
OFF, release the switch trigger.
VARIABLE SPEED
The switch trigger delivers higher speed and torque with
increased trigger pressure and lower speed with decreased
trigger pressure.
NOTE: You might hear a whistling or ringing noise from the
switch during use. Do not be concerned; this is a normal
part of the switch function.
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
See Figure 3, page 11.
The direction of bit rotation is reversible and is controlled
by a selector located above the switch trigger. With the drill
held in normal operating position, the direction of rotation
selector should be positioned to the left of the switch trigger
for drilling. The drilling direction is reversed when the selector
is to the right of the switch trigger.
Setting the direction of rotation selector in the
OFF (center
lock) position helps reduce the possibility of accidental start-
ing when not in use.
CAUTION:
To prevent gear damage, always allow the chuck to
come to a complete stop before changing the direction
of rotation.
To stop the drill, release the switch trigger and allow the
chuck to come to a complete stop.
NOTE: The drill will not run unless the direction of rotation
selector is pushed fully to the left or right.
