7
SyMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SyMBOL NAME DESIGNATION/EXPLANATION
Li - Ion
Recycle Symbols
This product uses nickel- cadmium (Ni-Cd) and lithium-ion
(Li-ion) batteries. Local, state, or federal laws may prohibit disposal
of batteries in ordinary trash. Consult your local waste authority
for information regarding available recycling and/or disposal
options.
WARNING:
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities con-
tains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to
these chemicals: work in a well ventilated area, and work with approved safety equipment, such as those dust masks
that are specially designed to filter out microscopic particles.
FEATURES
PRODUCT SPECIFICATIONS
Motor ......................................................................12 V DC
Blade Diameter ......................................3-3/8 in. (85.7 mm)
Blade Arbor ..............................................................15 mm Cutting Depth at 0º ................................................ 15/16 in.
Cutting Depth at 45º .................................................. 3/4 in.
No Load Speed ..................................... 2,000 r/min. (RPM)
kNOW yOUR CIRCULAR SAW
See Figure 1, page 14.
The safe use of this product requires an understanding of
the information on the product and in this operator’s manual
as well as a knowledge of the project you are attempt-
ing. Before use of this product, familiarize yourself with all
operating features and safety rules
.
BEVEL ADJUSTMENT kNOB
The bevel adjustment knob allows you to set the circular
saw for bevel cuts from 0° to 45°.
BLADE WRENCH STORAGE
Convenient wrench storage for quick blade changes.
DEPTH ADJUSTMENT kNOB
The depth adjustment knob adjusts the depth of cut from
0 in. to 15/16 in.
LOCk-OFF BUTTON
The lock-off button reduces the possibility of accidental
starting.
SPINDLE LOCk BUTTON
The spindle lock button allows you to secure the blade when
turning the blade screw.
WIDTH OF CUT SCALE
When making straight cross cuts or rip cuts, the scale can
be used to measure up to 2-3/4 in. on the right side of the
blade, and up to 1 in. on the left side of the blade.
