Electrical, Leg location & suggested floor drain detail, Dimensions capacities – Cleveland Range SEL-40-T1 User Manual
Page 2: Flanged foot detail
DPK
(OPTION)
39"
991mm
35"
889mm
(RIM
HEIGHT)
71"
1804mm
75
28 3/4"
731mm
(PAN
SURFACE)
A
H
B
(PAN SURFACE)
41"
1042mm
H C
25 15/16"
(659mm)
3 7/8" (99mm)
C
5 1/4"
(134mm)
(FAUCET
OPEN)
30"
(762mm)
5"
(127mm)
(MANUAL
TILT HANDLE)
D
RECOMMENDED FLOOR
SLOPE 1" (26mm) IN 4' (1220mm)
FLOOR DRAIN
PIPE DRAIN RECOMMENDED
MINIMUM VALVE SIZE PLUS 1" (26mm)
4" (102mm) MINIMUM
6" (153mm) RECOMMENDED
DPK
(OPTION)
LEG LOCATION &
SUGGESTED FLOOR DRAIN DETAIL
MODEL
SEL-30-T1
SEL-40-T1
A
37 7/8"
(963mm)
49 7/8"
(1267mm)
RIGHT:
4" (102mm) (manual tilt)
1" (26mm) (power tilt)
LEFT: 0", REAR: 0"
CLEARANCE
DIMENSIONS
CAPACITIES
B
24 1/2"
(623mm)
36 1/2"
(928mm)
F
18 1/4"
(464mm)
24 1/4"
(616mm)
G
5 3/4"
(146mm)
5 3/4"
(146mm)
H
8"
(204mm)
8"
(204mm)
C
31 3/4"
(807mm)
43 3/4"
(1112mm)
D
12"
(305mm)
18"
(458mm)
In 4 oz. servings. Other sizes may be calculated.
30 gallons / 115 Liters.............960
40 gallons / 150 Liters...........1280
SEL-30-T1
390 LBS. (178 KG.)
SEL-40-T1
410 LBS. (187 KG)
APPROXIMATE
SHIPPING WEIGHTS
9 1/2" (241mm)
(PAN DEPTH)
NOTE: OPTIONAL 2" TD VALVE SHOWN IN GRAY
FOR OPTIONAL 2" TD VALVE
INCREASE FLOOR
DRAIN GRATE SIZE TO
24" x 20" (610mm x 508mm)
FLOOR
DRAIN
GRATE
12" x 20"
(305mm x
508mm)
H C
2 1/4"
(57mm)
7/16"Ø, 3 HOLES
ON
3 1/8" (80mm) B.C.D.
FLANGED FOOT DETAIL
(REAR LEGS ONLY
)
120
°
120
°
4 7/8" (124mm)
9/16" (15mm)
1" (26mm)
(MAXIMUM
ADJUSTMENT
2" (51mm)
38"
966mm
TD 2 OUTLET
42 3/4"
1086mm
TD 2
23"
585mm
SECT.
XII
PAGE
10
0707
Litho in U.S.A.
(NOT TO SCALE)
NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are U.L., NSF, CGA, CSA, ETL and others.
Volts Ph
Hz
Total Amps
Wire
Watts
Size
SEL-30-T1 (Standard Wattage)
208
1
60
12000
57.7
4
208
3
60
12000
33.3
8
240
1
60
12000
50.0
6
240
3
60
12000
28.9
8
380
1
50
10013
26.3
8
380
3
50
10013
15.2
12
416
1
50
12000
28.8
8
416
3
50
12000
16.7
10
480
1
60
12000
25.0
8
480
3
60
12000
14.4
12
SEL-30-T1 (High Wattage)
208
1
60
16020
77.0
3
208
3
60
16020
44.5
6
240
1
60
16020
66.8
4
240
3
60
16020
38.5
6
380
1
50
13367
35.2
8
380
3
50
13367
20.3
10
416
1
50
16020
38.5
6
416
3
50
16020
22.2
10
480
1
60
16020
33.4
8
480
3
60
16020
19.3
10
Volts Ph
Hz
Total Amps
Wire
Watts
Size
SEL-40-T1 (Standard Wattage)
208
1
60
18000
86.5
2
208
3
60
18000
50.0
6
240
1
60
18000
75.0
3
240
3
60
18000
43.3
6
380
1
50
15019
39.5
6
380
3
50
15019
22.8
10
416
1
50
18000
43.3
6
416
3
50
18000
25.0
8
480
1
60
18000
37.5
6
480
3
60
18000
21.7
10
SEL-40-T1 (High Wattage)
208
3
60
24000
66.6
4
240
3
60
24000
57.7
4
380
3
50
20026
30.4
8
416
3
50
24000
33.3
8
480
3
60
24000
28.9
8
ELECTRICAL
