Do not place the charger in an area of extreme heat or
cold. It will work best at normal room temperature.
NOTE: The charger and battery pack should be placed in
a location where the temperature is more than 50°F but
less than 96°F.
The battery pack may become slightly warm to the touch
while charging. This is normal and does not indicate a
problem.
After charging is complete, the green LED will remain on
until the battery pack is removed from the radio/charger
or charger is disconnected from the power supply.
NOTE: Always remove the battery pack from the radio/
charger before unplugging the unit from a power source,
or before plugging the unit into a power source.
To remove the battery pack from the charger, depress
latches and pull up on the battery pack.
When the battery pack is fully charged, remove it from
the charger.
OPERATION
CHARGING A HOT BATTERY PACK
When using a tool continuously, the battery pack may
become hot. A hot battery pack may be placed directly onto
the charger port but charging will not begin until the battery
temperature cools to within acceptable temperature range.
When a hot battery pack is placed on the charger, the red
LED will begin flashing and the green LED will be off. When
the battery pack cools to approximately 120°F (40°C), the
charger will automatically begin charging.
CHARGING A COLD BATTERY PACK
A cold battery pack may be placed directly onto the charger
port but charging will not begin until the battery temperature
warms to within acceptable temperature range. When a cold
battery pack is placed on the charger, the red LED will begin
flashing and the green LED will be off. When the battery
pack warms to approximately 32°F (0°C), the charger will
automatically begin charging.
LED FUNCTIONS
MODE
BATTERY PACK
GREEN
LED
RE15D
LED
ACTION
Power On
Without
battery pack
OFF
ON
Ready to charge battery pack.
Testing
Hot battery pack
OFF
Flashing
When battery pack reaches cooled temperature, charger
begins fast charge mode.
Cold battery pack
When battery pack reaches warmed temperature, char-
ger begins fast charge mode.
Deeply discharged
Charger pre-charges battery until normal voltage is
reached, then begins fast charge mode.
Defective
Defective
OFF
Fading
Battery pack or charger is defective.
• If defective, try to repeat the conditions a second time by removing and reinstalling the battery pack. If the LED status repeats a
second time, try charging a different battery.
• If a different battery charges normally, dispose of the defective pack (see Maintenance section).
• If a different battery also indicates “Defective,” the charger may be defective.
Charging
Fast charging
Flashing
ON
Battery is being charged.
Charged
Battery full
ON
OFF
Fast charging is complete; charger maintains charge
mode.
Energy
Save Mode
Battery full /
Energy Save mode
Fading
OFF
Battery pack is fully charged and charger is in
Energy Save mode.
