- 8 -
CONTROL & DISPLAY FUNCTIONS
1. LEFT BALANCE INDICATOR: This will light up when you change the output balance
of the amplifier. Note that the amount of deviation from center balance will be
shown in dB on the display.
2. INPUT INDICATOR: When the MD 308 is powered on, this LED will be lit.
3. RIGHT BALANCE INDICATOR: This will light up when you change the output
balance of the amplifier. Note that the amount of deviation from center balance
will be shown in dB on the display.
4. POWER SWITCH: Turns the MD 308 ON, showcased by the lit red LED above
the knob.
5. POWER METER: The right channel power output watt meter indicates the power
output of the right channel, the left channel power output watt meter indicates
the power output of the left channel. Please read the info on
Power VU – meters .
6. INPUT/VOLUME: When adjusting the volume either with the remote or manual
knob, a number from 0-50 will appear in this display. When changing the input
source, the source chosen will be shown in the display.
7. VOLUME CONTROL: The volume can be controlled manually or via the remote
control.
