Magnum Dynalab MD-109 - Manual (Page 14)

OPERATING THE CONTROL SYSTEM USING THE HANDHELD
1. To turn on the power push the on button, to turn the power off push the off
button
2. To tune up and down push the tune up and tune down buttons
3. To directly access a station, push the numbers representing the frequency of
the station.
4. To store presets:
a) Tune the station frequency you want to store, make sure you are tuned
perfectly tuned to the station (as indicated by the center tune meter).
b) Push store and then the preset location, must be two digits, i.e.: 01
c) Repeat steps 1 & 2 for other presets
d) To recall a preset, you can push the preset button and the number of
the preset you want.
e) To reset or purge the presets press “p” then “s” within 5 seconds.
Problem Probable Cause Probable Solution
Presets will not store Speed of entry of preset
position too slow When entering the preset
location do it fairly quickly
Distance that the
remote will work is
very short Batteries are weak Change the batteries
Three “AAA”
Tuner will not turn on AC not connected
The infra red sensor is
blocked Check power cord
Remove anything sitting in
front of the unit
- 14 -
