PALMER POWER STATION
LOW NOISE BATTERY POWER SUPPLY/CHARGER
REVISION P
r
B – DECEMBER 2011
Copyright © 2011, M2Tech Srl
11
M2Tech
www.m2tech.biz
6. Technical Specifications
Supply voltage: ................................. 100-240V
AC
, 50-60Hz
Power consumption: ......................... 2.5A peak, 60VA rated
Fuse:................................................. 2 x T2.5A
Output voltage: ................................. 15V
DC
(battery)
Output current:
1A (peak, both outputs)
Output noise: .................................... 20µVrms (20-20,000Hz bandwidth, 200mA out)
Output regulation:
TBD (0 to 500mA output current)
Battery capacity: ............................... 3400mAh
Battery duration: .............................. min. 12 hours (@ 240mA output current)
Battery charge time........................... 3.5 hours +/- 30 minutes
Battery charge cycles........................ 1000
Operative temperature range:........... 0°C to 40°C
Size: ................................................. 200x50x200mm (w x h x d, cabinet)
200x55x210mm (w x h x d, with connectors and feet)
360x120x260mm (w x h x d, box)
Weight:.............................................. 2.5kg (unit only)
3kg (box)
