order with regards to activation, by pushing this button. In the process, LED 3 blinks.
At the end of disable process, LED 3 turns off.

2) Single output enable buttons. When the VAN DER GRAAF is active (both LED 4
and 3 on), it is possible to toggle each output by pushing the related button.

3) General enable LED. It’s on when the VAN DER GRAAF is active. It blinks when
enabling and disabling outputs.

4) Power on LED. It’s on when the VAN DER GRAAF is powered.

5) Single output enable LED’s. Each LED is on when the related VAN DER GRAAF
output is enabled.
