YOUNG DSD
DIGITAL-TO-ANALOG CONVERTER AND PREAMPLIFIER

REVISION 1.1 – march 2014

M2Tech

www.m2tech.biz

7.11. Checking Firmware Revision

The YOUNG DSD is a complicated device in which different microcontrollers interact for
correct operation. It’s possible, whenever needed, to update all controllers firmware
by the USB port of the YOUNG DSD. Therefore it’s necessary to access to YOUNG DSD
current firmware release information to decide whether an update is required or not.
This can be accomplished by accessing the menu as one of the items is that related
to firmware revisions, as shown in Fig. 13.

FW REV FPGA: 1.0
USB:1.1 uC: 1.0

Figure 13

Of course, a user can’t change the displayed values by the front panel controls nor
the remote: they only change when a firmware update is performed as described in
chapter 10.

7.12. Power Off and Standby
