SKU 66878 For technical questions, please call 1-800-444-3353. Page 5
to prevent
SeriouS injury
FroM AccidentAl
operAtion or electric
SHock:
Before assembly, cleaning or
adjustment, make sure the
switch is turned off, the cord
is unplugged, and the unit has
cooled.
note: For additional information regarding
parts listed, refer to Assembly dia-
gram at the back of the manual.
Adjustment
Knob (4)
Fan Body (1)
Stand Base (3)
Stand
Arm (2)
Screw (5)
Figure 1
1. Place the Fan Body (1) on a flat and
stable surface.
Remove the Screws (5) and set
2.
aside.
Slide the Adjustment Knobs (4) onto
3.
the bolts on the Stand Arms (2) and
loosen the Stand Arms slightly by
turning the Adjustment Knobs counter
clockwise.
Insert the ends of the Stand Base (3) 4.
into the Stand Arms.
Align the holes in the sides of the
5.
Stand pieces and thread the Screws
in place.
Adjust the body of the fan to the de-
6.
sired angle, then Tighten the Adjust-
ment Knobs.
operAtion
read the entire ruleS For
SAFe operAtion section at
the beginning of this manual
including all text under
subheadings therein before set
up or use of this product.
Turn the knob on the back of the Fan 1.
Body (1) to Off.
Set the Fan on a dry, stable surface.
2.
Plug the power cord into a standard 3.
120V AC outlet.
Turn the Knob on the back of the fan
4.
to the desired setting: Low, Medium
or High.
Adjust the tilt of the Fan Body by
5.
loosening the Adjustment Knobs (4),
changing the tilt of the body, then
tightening the Adjustment Knobs.
When done, turn the Knob on the
6.
back of the Fan Body to Off and un-
plug.
note: It is normal for the motor of the
Fan to feel warm to the touch dur-
ing operation. The motor is thermally
protected and will automatically shut
off when it overheats for any reason.
If this happens, immediately discon-
nect the Fan from the power outlet.
