19 25 futaba, 24 hitec, 23 airtronics / jr / ko – Axial Racing AX90001 User Manual
Page 20
26
19
25
Futaba
Install when servo
is in neutral position.
Bei Montage auf
Neutralstellung achten.
AXA186
AXA186
AXA186
AXA186
AX30441
AX30442
AXA1331
AXA1331
AXA1331
AXA695
AXA1101
AXA1331
25
AX80005
2
AX80005
2
AX80005
1
AX80006
3
24
Hitec
AX80006
2
23
Airtronics / JR / KO
AX80006
1
AX80006
1,2,3
AX80005
1
106mm
AXA1331
Flanged Ball 3x5.8x7mm
x2
AX30441
6x106mm
x1
AXA1331
Flanged Ball 3x5.8x7mm
x2
AX30442
6x33mm
x1
33mm
27
90°
AXA695
M3x10mm
x1
AXA1101
Cone Washer 3x6.9x2
x1
AXA186
M3x16mm Set Screw
x2
AXA186
M3x16mm Set Screw
x2
!
Note Direction
Richtung beachten
