SAFETY INSTRUCTIONS
Please fully understand and follow all safety instructions
outlined in this booklet. Failure to do so could result in
severe injury.
• Do not use open flame heaters in your ice shelter.
Open vents for cross ventilation.
• Ice Armor fabric will melt when contact is made with
hot surfaces (i.e., heaters).
• Never leave shelter unattended when set up.
• Due to the increase in traffic (snowmobiles, autos,
etc.) on area lakes, ice fishing can be hazardous at
night. If you choose to fish at night or in poor visibility
conditions, be sure to take precautions with lights or
reflectors to show drivers your whereabouts.
Death from Asphyxiation may result from use of
oxygen depleting heaters. Open all vents for
fresh air ventilation.
Injury or death may result from fire if tent fabric is
exposed to open flame.
Tent fabric is not fireproof. Fabric will burn with
extended exposure to open flame. Do not use
open flame products inside tent. Tent fabric is
treated with fire retardant. Application of any for-
eign substance may render the flame retardant
properties ineffective.
Night time: exterior reflectors must be visible to
reduce risk of collisions.
This tent is made with flame resistant fabric
which meets CPAI-84 specifications.
CLAM 5600 PARTS LIST
If you need replacement parts,
contact Clam Corporation’s
Customer Service at
763-231-4120 or
[email protected].
Customer service hours:
9am – 4pm, weekdays,
central time.
Page 2
ITEM #
DESCRIPTION
QTY.
PART NO.
1
TENT
1
101841
2
CLAM FLOOR 60 X 32
2
101156
3
CLAM CENTER 60 X 9
1
101161
4
PLYWOOD, 1/2 X 11-7/8"
2
101184
5
HOLE COVER, 12 X 24
2
101185
6
SPREADER TUBE
2
101186
7
LATCH
8
101189
8
RIVET, 3/16 X 5/8
8
101190
9
NUT, KEPS
8
101191
10
NUT, NYLOCK
6
101163
11
ROPE, 9'
1
101095
12
ROPE, 3/8 X 20" BRAIDED POLY
2
101200
13
STRAP ATTACHMENT
10
101202
14
LATCH, RUBBER W/PIN
2
101203
15
WASHER, 1"
4
101206
16
SCREW, 3/4"
4
101212
17
A SUPPORT BRACE
2
101197
18
B SUPPORT BRACE
2
101192
19
SCREW, 1-1/2" TRUSS HEAD
2
101208
20
CARRIAGE BOLT, 5/8"
8
101209
21
DOME POLE
1
101182
22
STAPLE, 1-1/2"
6
101210
23
BOLT, 1-3/4"
4
101211
24
SCREW, 3/4"
10
101207
25
SQUARE POLE ASSY
4
101645
26
ROUND POLE ASSY
4
101646
27
HOOP POLE
2
101171
28
HINGE CONNECTOR
1
101641
