TECHNICAL DATA
DIMENSIONS
Height
1345mm
Width 500mm
Depth 600mm (excluding door handles)
GENERAL
Gas connection
Rp 1 /
2
( 1 /
2
” BSP female)
Pressure test point Grill injector
Gas rate adjustment None
Aeration adjustment None
Electrical connection Flexible cord fitted with a 3 pin 13 amp plug
230/240V a.c. 50Hz. 3A fuse.
19
INSTALLATION INSTRUCTIONS
BURNER HEAT INPUT INJECTOR HEAT INPUT INJECTOR
HOTPLATE
Front left
HOTPLATE
Rear right
HOTPLATE
Front right
HOTPLATE
Rear left
GRILL
OVEN
3.0 kW
2.0 kW
1.0 kW
4.1 kW
2.5 kW
128
102
72
150
115
2.8 kW (205g/h)
1.8 kW (130g/h)
1.0 kW (75g/h)
3.6 kW (260g/h)
2.5 kW (180g/h)
82
65
50
2.0 kW 102 1.8 kW (130g/h) 65
95
75
NATURAL GAS LPG
