Troubleshooting
• If the unit is not functional – check main power supply is ʻonʼ and check fuses.
• If after trying this solution you still have a problem contact CHAUVET.
Contact Chauvet
USA
Tecnical Assistance: 1-800-762-1084 (954) 929-1115
E-Mail [email protected]
Caution
Do not obstruct the air vents.
Never use the SF-4005 with DMX lighting.
Only use SF-4005 in Timer position when using effects lighting.
No user serviceable parts inside, please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Technical Specifications
Power Input: AC 120V 60 Hz / 230V 50 Hz
Output Load: Maximum Load of 5A per Channel
Fuse: 10A 125V or 6.3A 250V
Timed Chase Speed: 2 minutes to 15 minutes
Dim: 7.9 x 5.1 x 2 in
200 x 130 x 50 mm
Weight: 2.2 lbs / 1.0 Kg
User Informtion (Please complete for your records)
Date Purchased: / / Serial No: ________________
Dealer Stamp Model: SF-4005 2/4 CH Timer
2/4 CH Timer
SF-4005
User Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29th Ct.
Hollywood, Florida, USA 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
www.ChauvetLighting.com
