3. Parts List
KEY PARINO. DESCRtPTION KEY PART NO. DESCRIPTION
01 0109201 UPHTOOL4" 51 0139754 WHEEL
02 6030961 WINDOW FOR 4-TOOL 52 0130440 BASE
03 6030966 BRUSH FOR 4" TOOL 53 0100105 AUTOMIX ASSY
04 0159155 TUFF STAIN TOOL 3' WIDE 54 0139131 BARE FLOOR ATTACHMENT
OS 0149155 BRUSH FOR 3'TOOL 55 0130050 PIVOT ARM-RIGHT
06 0139850 WINDOW FOR 3-TOOL 56 0107370 ARM RETAINER-RIGHT
07 0109210 HOSE & GRIP ASSY 57 0133261 ELEVATOR LEVER RIGHT
08 0142987 TOP ASSY 56 0106105 SPRAY TIP
09 0134435 TANK HANDLE 59 0102602 T CONNECTOR(REGULAR)
10 0134423 HANDLE UP/FRONT(16981) 60 0107371 ARM RET/UNER-LEFT
10 0134445 HANDLE UP/FRONT(1697) 61 0133260 ELEVATOR LEVER LEFT
10 0134446 HANDLE UP/FRONT(1698) 62 0108420 SPRING-ELEVATOR LEVER
11 0139168 TRIGGER-HANDLE 63 0130051 PIVOT ARMLEFT
12 0137511 PUSH ROD41ANDLE 64 0101174 FLOOR BRUSH ASSY
13 0108422 SPRING-PUSH ROD 65 0108451 WIPER-BARE FLOOR
14 0109592 VALVE ASSY-TRIGGER 66 0104445 WIRING HARNESS(1697)
15 0134424 HANDLE UP/REAf^16981) 66 0104451 WIRING H/UmESS(1696)
15 0134426 HANDLE UP/REAR(1697) 67 0136750 CADDY-STORAGE
IS 0134428 HANDLE UP/REAR(1698) 68 0104501 HEATER
16 0140325 FLOAT ASSY 69 0108801 SWITCH-HEATER UGHTED(169
17 0130212 BAFFIE-TANK 69 0108602 SWITCH-POWER
18 0100315 BLADDER 69 7108617 SWnCH-REO(1698)
19 0139040 TANK 70 0134414 HANDLE LO/REAR(16981)
20 0104057 GASKET FOR DRAIN CAP 70 0134416 HANDLE LO/REAR(1697)
20 0131782 DRAIN CAP 70 0134418 HANDLE LO/REAR(1698)
21 0109148 CREVICE TOOL 71 0105601 UGKTASSY(1698 & 16981)
22 0104052 SEAL-OVM. 72 0134413 HANDLE LO/FRONT(169S1)
23 0139860 WINDOW-BASE 72 0134415 HANDLE LOEnONT(1697)
24 0136986 OIVERTER(16981) 72 0134417 HANDLE LO/FRONT(1698)
24 0136987 DIVERTER(1697) 73 0106215 E-RING
24 0136988 DtVERTER{169S) 74 0101256 BUSHING-WHEEL
25 0135171 BASE-KNOB 75 0101185 TURBO BRUSH ASSY
26 0135170 KNOB-OIVERTER 76 0108550 RUBBER BLOCK-HEATER
27 0107067 PLUNGER-DIVERTER 77 0102812 POWER CORD(1697 & 1698)
28 0108421 SPRINGOIVERTER 78 0102811 POWER CORD
29 8807030 SCREW *8X3/4' 79 0101651 CAP-FLOW INDICATOR
30 0104054 GASKET-DIVERTER 80 0107635 SPINNER-FLOW INO
31 0134907 HOUSING(16981) 81 0103510 FILTER-FLOW INO
31 0134908 HOUSING(1697} 82 0100481 BASE-FLOW IND
31 0134909 HOUSING<169a) XX 0102485 CLAMP-LARGE
32 0101065 SHAMPOO BOTTLE XX 0102490 CLAMP-SMAU
33 0101795 CAP ASSY-BOTTLE XX 0104950 WIRING JUMPER
34 0104050 GASKET-SHORT DUCT XX 0105520 BEARING4R.OOR BRUSH
35 0103161 AIR DUCT SHORT XX 0105900 OWNERS MANUM^16981)
36 0104051 GASKET MOTOR INTAKE XX 0105912 OWNERS MANUAL(1697)
37 0132984 COVER-WOTOR XX 0105925 OWNERS MANUAL(1698)
XX 0133722 CORD WRAP
39 0132991 COVER-BELT(16981) XX 0139440 10* TUBE-CLEAR VINYL
39 0132992 COVER-B£LT(1697) XX 0139442 15* TUBE-CLEAR VINYL
39 0132993 COVER-6ELT(1698 XX 0139444 5" TUBE-CLEAR VINYL
40 0104053 O-RING FOR ABOVE XX 0139446 2r TUBE-CLEAR VINYL
41 0103160 AIR DUCT-LONG XX 0139447 14'TUBE URETHANE
42 0104056 GASKET-MOTOR XX 0139448 STTUBE-UI^THANE
43 0105970 MOTOR ASSY XX 7103418 GASKET MATERUU. .136* DIA
44 0107185 PUMP ASSY XX 8807202 SCREW «6-19 X1/r
4S 0100620 BELT-PUMP XX 8807204 SCREW 10-32 X 2.75*
46 0100621 BELT-BRUSH XX 8805040 NUT 10-32 BLACK
47 0102603 T CCMNECTOR(ODO BARB) XX 0100290 SCREWS & NUTS KTT
48 0140710 RECEIVER AUTOLOAD
49 0135580 PB1ALHANDLE RELEASE
SO 0100170 A)OE-WHEEL
