27
103574
PARTS LIST
CGN10T
CGN10TL
This list contains replaceable parts used in your heater. When ordering parts, follow
the instructions listed under Replacement Parts on page 28 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098304-01 Screw, #10 x 3/8" 2
2 099467-02 Front Panel Assembly,
Earthtone (CGN10T) 1
099467-05 Front Panel Assembly,
Ivory (CGN10TL) 1
3 099318-04 Grill Guard 1
4 101108-01 Grill Guard Clip 2
5 102018-01AA Bottom Glass Retainer 1
6 098260-03 Glass Panel 1
7 098532-03AA Top Glass Retainer 1
8 M11084-38 Screw, #8 x 3/8" 8
9 098352-03BR Deflector Unit 1
10 098271-03 Ignitor Cable 1
11 098249-01 Nut, M5 2
12 100701-03 ODS/Pilot Assembly 1
12-1 098514-01 Thermocouple 1
12-2 098594-01 Ignitor Electrode 1
13 099386-02 Burner 1
14 099387-11 Pilot Tubing 1
15 098251-03 Injector 1
16 099463-01 Injector Holder 1
17 099415-01 Pressure Regulator 1
18 102863-01 Burner Tubing 1
19 102864-01 Regulator Tubing 1
20 102492-01 5/16" Male Connector 1
21 102493-01 1/4" Male Connector 1
22 098522-07 Thermostat Gas Valve 1
23 102571-01 Cabinet Assembly, Brown (CGN10T) 1
102571-03 Cabinet Assembly, Ivory (CGN10TL) 1
24 102445-01 Piezo Ignitor 1
25 098275-01 3/8" NPT Male Plug 2
26 099553-01 Pilot Shield 1
27 098303-02 Screw, #6 x 5/16" 2
PARTS AVAILABLE - NOT SHOWN
102471-01 Control Position Label 1
100642-02 Assembly, Hardware 1
