1.4 FEATURES
R3G Series --- 2 + 1 Redundant power supply ( w/PFC )
2+1, Hot swappable, Hot pluggable, AC Input, 650 W output
Compact size, 650W + 350W, PFC, ATX12V / EPS12V outputs
u True Redundant design (Passive backplane)
u All circuit been designed in the power module
u Hot swap, Hot plug ability
u Full range operations
u Active Power Factor Correction (PFC) built
u ATX 650W + 350W output power
u Balance load sharing design
u Remote sensing design
u Meet FCC, CISPR EMI regulation
u Smart I
2
C interface design (optional feature )
u Space save / click type handle design
u Three EMI Line Filter inlets design
u One piece 40 m/m ball bearing DC fan on power module design
u A 80 m/m ball bearing DC fan on power system rear side
1.5 PRE-INSTALLATION
Before installing the R3G unit into the system chassis, please review the
following drawings page 4 ~ 17 and find out the best way to match them.
1.6 DRAWING (page 4 ~ 17)
1.7 SPECIFICATIONS (page 18)
