1.6 SPECIFICATION
INPUT CHARACTERISTICS: DR2G-6350P
A INPUT CHARACTERISTICS
1 VOLTAGE DC -36V -72V
2 INPUT CURRENT 12A MAX.FOR -48VDC
3 INRUSH CURRENT 20A MAX.FOR EACH POWER UNIT
B OUTPUT CHARACTERISTICS
OUTPUT OUTPUT CURRENT REGULATION OUTPUT RIPPLE &
VOLTAGE MIN. MAX. PEAK LOAD LINE NOISE MAX. [P-P]
+5V 3.0A 35A 5% 1% 50mV
-5V 0.1A 0.5A 5% 1% 120mV
+12V 2A 22A 10% 1% 120mV
-12V 0.1A 0.8A 10% 1% 150mV
+3.3V 1.0A 20A 5% 1% 50mV
+5VSB 0.1A 2A 5% 1% 50mV
REMARK: 1. TOTAL CURRENT OF +5V AND +3.3V NOT EXCEED 35A
C SPECIFICATION
1 TEMPERATURE RANGE OPERATING 10 40 STORAGE -20 70
2 HOLD UP TIME 1.6mS MIN. AT FULL LOAD & -48VDC INPUT VOLTAGE
3 DIELECTRIC WITHSTAND INPUT/OUTPUT 1500 VAC FOR 1 minute
INPUT TO FRAME GROUND 1500 VAC FOR 1 minute
4 EFFICIENCY 65% TYPICAL AT FULL LOAD
5 POWER GOOD SIGNAL ON DELAY 100mS TO 500mS OFF DELAY 1mS
6 OVERLOAD PROTECTION 110 160% MAX
7 OVER VOLTAGE PROTECTION +5V 5.7V 6.5V +3.3V 3.9V 4.3V +12V 13.3V 14.3V
8 SHORT CIRCUIT: 5V,12V,3.3V, AUTO-RECOVERED: 5VSB,-5V,-12V
9 . EMI : FCC CLASS A , CISPR 22 CLASS A
10 SAFETY UL 1950, CSA 22.2 NO/950, TUV IEC 950
11 . REMOTE ON / OFF CONTROL
12 . FAULTY ALARM METHODS: LED, BUZZER, TTL SIGNAL
13 HOT-SWAPPABLE / HOT PLUGGABLE REDUNDANCY FUNCTION
14 N +1 BALANCE LOAD SHARING DESIGN ON 5/12/3.3V CHANNEL
15 . REMOTE SENSING DESIGN
16 . ISOLATION: BUILT-IN THE POWER MODULE
17 DIMENSION 82*101*276/300 (H*W*D)mm,276mm— W/O REAR DC FAN
18 . COOLING: TWO 40mm DC FANS (ONE IN EACH MODULE)
ONE 80mm DC FAN (REAR SIDE)
