TrendsAudio TA-10 Class-T Stereo Amp User Manual
Page 4
Trends TA-10 User Guide
Section 5 Specifications
7
5
5
.
.
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
5.1 Specification of the Amplifier Unit
T-Amp IC
Tripath TA2024
Output Power
2x15W @4ohm
2x10W @8ohm
Signal-to-Noise Ratio (SNR)
98dB
Dynamic Range
98dB
IHF IM Distortion
0.10% @ 1W, 4ohm
THD+Noise Audiophile
Quality
0.03% @ 9W 4ohm
0.1% @ 11W 4ohm
0.1% @ 6W 8ohm
High Power
10% @ 15W 4ohm
10% @ 10W 8ohm
Power Efficiency
81% @ 15W 4ohm
90% @ 10W 8ohm
Input
Audio IN RCA (Left/Right) x 1
Power Socket (5.5mm/2.1mm) x 1
Output
Speaker OUT (Left) x 1 pair (+/-)
Speaker OUT (Right) x 1 pair (+/-)
Other Switch & Knob
Power ON/OFF switch x 1
Power Indicator (Blue LED) x1
Volume Knob x 1
Power Supply
DC 12V-13.2V (max.)
Dimensions
(W)76mm x (H)46mm x (D)114mm[case only]/150mm [incl.
sockets & knob]
Weight 500g
5.2 Specification of the AC Adaptor
AC Input
Universal AC 100V-240V/50-60Hz
DC Output
DC 12V 3A (36W)
Ripple & Noise
<= 50mV
Over-load Protection
105%-150%
Over-voltage Protection
115%-150%
Dimensions
(L)117mm x (W)48mm x (H)33mm
Weight 300g
* To continuously improve our product, we reserve the rights to change some specifications
without further notice.
Trends TA-10 User Guide
Section 6 Troubleshooting / Section 7 Accessories / Section 8 Contact Us
8
6
6
.
.
T
T
r
r
o
o
u
u
b
b
l
l
e
e
s
s
h
h
o
o
o
o
t
t
i
i
n
n
g
g
If your machine is out of order, it may not be very serious. Before you call your local
distributor or us to repair, you are suggested to check the following:
Symptoms
Possible Reasons
Handling Methods
power cords not properly
connected
properly connect the power
cords
cannot power ON
indicator not bright
power switch is OFF
switch ON the power
the volume level is too low
turn volume level higher
the audio cable not properly
connected
properly connect the audio
cable
the audio source (e.g. CD
player) not started playing
start playing the audio source
the audio source is mute or
connected with a headphone
(some player may auto-mute
the audio output when the
headphone is connected)
Disable the mute or unplug
the headphone connected, if
any.
no sound at all
the speaker cables not
properly connected
properly connect the speaker
cables
volume level cannot be adjust
by turning the volume knob
the amplifier configured as
pure power amplifier by
setting the jumpers in J2
reset the jumpers in J2 back
to integrated amplifier
7
7
.
.
A
A
c
c
c
c
e
e
s
s
s
s
o
o
r
r
i
i
e
e
s
s
•
AC adaptor (GM-120300) x1
•
3 pins power cord x1 (IEC female plug and male plug for your country standards)
•
User Guide x1
•
Warranty Card x1
8
8
.
.
C
C
o
o
n
n
t
t
a
a
c
c
t
t
U
U
s
s
ITOK Media Limited (Trends Audio)
Address:
Rm 1011-12, 10/F., Tower 1, Millennium City 1,
388 Kwun Tong Road, Kowloon, Hong Kong
Phone:
+852 2304 0730 (9am-6pm, HKG Time)
Fax:
+852
2566-5740
Email:
(Sales)
[email protected] (Support)
Web:
http://www.TrendsAudio.com
