Installation Manual 6

Reverse the Door Swing (optional)

This refrigerator has door hinges that allow you to change the
direction the door opens by moving the hinges on a diagonal to
the opposite side. Reverse the door swing before installing the
refrigerator in the vehicle.

1. Remove the doors (See Art01684):

- Remove the storage bins from the doors.

- Remove and save both hinge pins [1] from each door.

- Remove and save both hinge bushings [13] from each door.

- Pull the door latch and remove each door away from the

refrigerator.

2. Remove the upper mounting flange and the lower mounting

flange (See Art01683):

- Remove and save the four screws [2] from the upper

mounting flange [3] and from the lower mounting flange [4].

3. Change the position of the cabinet hinges and the strike

plate (See Art00983, Art01684, and Art01685):

- Remove and save the screws from the strike plate [5a].

- Remove and save the top and bottom of the three screws

[9] that are beside the strike plate.

- Do not remove the center screw.

- Remove and save the screws [20] from the upper and lower

cabinet hinges [14a].

- Make sure that the bottom of the solid box baffle is

18 inches to 18 1/2 inches above the bottom of the
enclosure [26] (4 1/4 inches to 4 3/4 inches above
the top of the lower intake vent opening REF) [27] .

- Make sure that the back of the solid box baffle is

perpendicular to the bottom of the enclosure.

- Make sure that the horizontal top of the solid box

baffle is even with the bottom edge of the upper
exhaust vent [13].

- Make sure that the vertical top edge of the baffle is

1/4 inch or less [20] below the lower rear corner of
the condenser [3].

- Make sure that there is 1/4 inch or less clearance

[21] between the rear of the condenser and the
baffle.

- Put each of these hinges on the other side of the refrigera-

tor [14b].

- Make sure that the offset of these hinges is positioned

down on upper cabinet hinge and up on the lower
cabinet hinge.

- Attach each of these hinges with screws.

- Remove and save the screws from the center cabinet

hinges [15a].

- Reverse each center hinge and put on the other side of the

refrigerator [15b].

- Attach each of these hinges with screws.

- Remove and save the screw [8] from the front box [6].

- Pull the front box away from the refrigerator and out from

under the controls [7] (See Art00983).

- Reverse the front box and put it on the opposite side of the

controls.

- Attach the front box to the refrigerator with the screw [8] that

was removed before.

- Put the strike plate on the opposite side of the refrigerator

[5b].

- Put the two screws into the holes that are beside the strike

plate.

4. Change the position of the door handles and the door

hinges (See Art01695 and Art00985):

- Remove the plastic cap that is opposite the upper hinge of

the upper door.

- Remove the screw [13] from the door handle [10] and the

screw [9] from the door hinge [11].

- Remove the round head screw(s) [12] and door handle

from each door.

- Remove the upper hinge of each door.

- Put each of these hinges on the other side of the door as

the lower hinge.

- Attach each of these hinges with the screws that were

removed from the other side.

- The recommended torque for each cap screw is 35 in.-

lbs.

- Remove the lower hinge of each door.

- Put each of these hinges on the other side of the door as

the upper hinge.
