Owner’s Manual 4
Wiring Pictorial
Use this wiring pictorial instead of the wiring pictorial that is in
the Owner’s Manual. The parts of the wiring pictorial are (See
Art01707)
1 ............................................................................ Display overlay
2 .............................................................................. Display board
3 .............................................................................. Divider heater
4 ....................................................... Thermistor / Light assembly
5 ............................................................ Igniter (gas models only)
6 ................................................................................ Power board
7 ................................................................... 120 VAC Power cord
8 ................................................................. 5 Amp fuse (120 VAC)
9 .................................................................. 5 Amp fuse (12 VDC)
10 ......................................................... Movable door-seal heater
11 .......................................................................................... Fans
12 .................................................................. Temperature switch
13 .................................................... Gas valve (gas models only)
14 ........................................................................... Door switches
15 ................................................................................ AC heaters
16 ............................................................................ Door contacts
17 .............. Ice maker water line heater (ice maker models only)
18 .......................... Temperature switch (ice maker models only)
19 .............................. Dispenser board (dispenser models only)
20 .................. Dispenser micro switch (dispenser models only)
21 ............................... Dispenser valve (dispenser models only)
22 ........................... Water valve heater (dispenser models only)
23 ............ Dispenser water line heater (dispenser models only)
24 ............. Ice maker water line heater (dispenser models only)
25 ......................... Temperature switch (dispenser models only)
26 ................................ Dispenser light (dispenser models only)
Replacement Parts
You may purchase replacement parts through your local RV
dealer or authorized Norcold Service Center. Water Dispenser Storage
To prepare the water dispenser for seasonal storage (See
Art01724):
CAUTION: Do not operate the water dispenser when
the ambient air temperature is 0° F. or lower. Damage to
the water solenoid valves and the water supply line can
occur.
1. Close the vehicle water supply valve to the refrigerator.
2. Remove the water supply line [1] from the water solenoid
valve [2].
3. Remove the water dispenser line [3] from the water solenoid
valve.
- Do not remove the foil heaters from around the water
solenoid valve and the water dispenser line
CAUTION: Drain the water dispenser. Failure to drain
the dispenser can cause damage to the dispenser
components and result in leaks.
4. Drain all of the water from the water supply line and the water
dispenser line.
NOTE: Make sure to use a large enough container to catch the
water that drains from the dispenser water line. The water
dispenser contains almost a quart of water.
5. Put the ends of the water lines and the water solenoid valve
each into a clean plastic bag.
6. Use tape to close each plastic bag around the water lines
and the water solenoid valve.
- Wash the reservoir, the cover, and the area around the
reservoir with a mild cleaner or a solution of liquid dish
detergent and warm water.
- If you need to clean behind the reservoir, remove the two
screws [3] that attach the reservoir to the refrigerator
cabinet.
- Gently clean behind the reservoir.
- Put the two screws back in the original position.
Message center for non-metal door models only
(optional):
An optional message center, for non-metal doors only, is
available for purchase. The message center [2] may be located
to the right of the water dispenser (See Art01703). You may use
magnets or self-stick notes to attach papers to the message
center.
To use the water dispenser after seasonal storage:
1. Remove the tape and plastic bags from the end of the water
lines and the water solenoid valve.
2. Connect the dispenser water line to the water solenoid valve.
3. Connect the water supply line to the water solenoid valve.
4. Open the vehicle water supply valve to the refrigerator.
5. Push and hold the dispenser arm until the water comes out
in a steady stream and does not sputter.
NOTE: You should discard and not use the first seven glasses
of water from the water dispenser.
