BASIC CONNECTION
DVD PLAYER
9
1
2
4
5
6
7
D: Connecting to AV amplifier with 2-channel input
connector
1.TV set (optional)
2.DVD / CD player
3.Video/ S-video cord (optional)
4.Amplifier with 2 channel input jacks
5.To audio input connector (L,R)
6.Left speaker
7.Right speaker
3
VIDEO
VIDEO OUT
S-VIDEO
AC 120V~
60Hz
3
R
L
AUDIO
