Smart Power Systems Mega Conditioner - Manual (Page 2)

SPECIFICATIONS
Output Voltage Regulation (VAC)
Dimensions Inches (mm) DxWxH
Capacity (Amps)
Input Voltage Range (VAC) / 50/60Hz
Net Weight (Lbs./Kgs.)
MODEL
Shipping Weight (Lbs./Kgs.)
MEGA1800
15
Input Plug
Receptacles
5-15P
Operating Environment Temperature: 0-40°C - Humidity: 0-90% (non condensing)
WARRANTY 2 Years
<0.5V
<10V
13 x 5.5 x 6.6 ( 330 x 140 x 168 )
Two 5-15R
15.7 / 6.7
17.2 / 7.8
MEGA2400
5-20P
Two 5-20R
20
17.5 / 7.9
19 / 8.6
Specifications subjects to change without notice.
120±6.5%
99-128
Over Voltage Protection - Disconnects the output when exceeds: (VAC) 140-145
SYSTEM DESCRIPTION IMPORTANT SAFETY INSTRUCTIONS
WARNING
SAVE THESE INSTRUCTIONS: This manual contains important instructions that should be followed during
installation and maintenance of the Mega Conditioner. • Install this unit in a controlled environment.
CAUTION
Risk of electric shock, do not remove cover. For service call Smart Power Systems at 800-772-7633.
• Avoid exposing the Mega Conditioner to direct sunlight, stoves or any other heat source.
• To prevent overheating, make sure that the ventilation openings of the unit are not covered.
• Keep unit away from moisture and dust.
FEATURES
This can be used with copiers, office equipment, computers and telecommunication
systems.
Mega Conditioner
INSTALLATION & OPERATION
1. Check in specifications if the unit has the same voltage/current rating as required.
2. Connect input power cable to wall outlet.
3."Power On" LED will turn on.
unit is running normal.
4. Connect power cable of the equipment to be protected to 's output outlets.
Mega Conditioner
Mega Conditioner
Mega Conditioner Network
RJ45 Jack/HUB
Protect the Network and increase download speeds up to 160%
1. Network Protector ( RJ45 )
2. Output Receptacles
3. Circuit Breaker
4. Input Power Cord
1
3
4
2
REAR
1
2
3
4
1. Green LED: Normal
Red LED: Reverse Polarity and No Ground
Disconnected Because of Over/Under Voltage
2. Buck
3. Boost
4. Voltage Meter
FRONT
Computer
SmartPower SYSTEMS • • • • • • • • • • • • • • • •
TM SmartPower SYSTEMS • • • • • • • • • • • • • • • •
TM
• Common Mode noise filtering: < 0.5 Volts
• Normal Mode noise filtering: <10 Volts
• Ultra power conditioning
• Voltage regulation
• Over and under voltage protection
• Site wiring fault indicator
• Ground loop current protection
DAMAGED UNIT ON ARRIVAL
Inspect unit for any damage on arrival . If damage is found, please contact
the shipping company to file insurance claim.
Mega Conditioner
Spike Transient Let Through Voltage (Common Mode) (N-G)
Spike Transient Let Through Voltage (Normal Mode) (L-N)
