153
Navigation*
Route guidance
The circle shows the current vehicle lo-
cation. The arrow in the circle designates
the current driving direction.
The remaining route is highlighted in color.
Display example 2:
On the right-hand side of the display the
symbol for the next driving maneuver is in-
dicated (here left turn).
On the very right is shown a distance bar.
The dark blue part of the bar and the infor-
mation 700ft, in this example, indicate the
distance to the next driving maneuver.
If available, the street following the driving
maneuver with its name is shown in the top
status bar (here
CHESTNUT RIDGE RD ).
The destination is marked with a flag on
the map, any stop-over destination is
marked with a flag
.
Changing map scale
The currently selected map scale is shown
in the left-hand corner of the bottom status
bar .
i
The colored highlight only appears
when the system has completed the
route calculation.
