Mercedes-Benz SLR-Class 2006 - Manual (Page 30)

29
At a glance
Instrument cluster
Item Page
1 Coolant temperature gauge
with
114
D Coolant temperature
warning lamp
302
2 Speedometer with
; Brake warning lamp,
USA only
300
3 Brake warning lamp,
Canada only
300
v ABS/ESP ® warning
lamp
298
> Gearshift indicator
lamp
303
< Airbrake warning lamp 303
L Left turn signal
indicator lamp
K Right turn signal
indicator lamp
Item Page
3 Left multifunction display
with
ț Outside temperature 115
ț Main odometer 117
4 Reset button 113
5 Tachometer with 115
A High beam headlamp
indicator
109
? Engine malfunction in-
dicator lamp, USA only
301
± Engine malfunction in-
dicator lamp, Canada
only
301
- Antilock Brake System
(ABS) indicator lamp
299
X Tire pressure warning
lamp
305
Item Page
1 Supplemental
Restraint System (SRS)
indicator lamp
304
< Seat belt telltale 304
6 Right multifunction display
with
ț Current gear selector lever
position/gear range 117,
170,
171
ț Trip odometer 117
ț Automatic transmission
shift program mode 117,
173
ț Clock 131
= Engine oil temperature
indicator
303
7 Fuel gauge with
A Fuel reserve warning
lamp
303
