191
Controls in detail
Automatic climate control*
Item
1 Thumbwheel for air volume control
for adjustable left side air vent
2 Left side air vent, adjustable
3 Fixed air vent for defrosting left side
window
4 Left center air vent, fixed
5 Thumbwheel for air volume control
for fixed/adjustable left center air
vents
6 Left center air vent, adjustable
7 Cockpit air vent
8 Thumbwheel for air volume control
for cockpit air vent
9 Right center air vent, adjustable
a Thumbwheel for air volume control
for fixed/adjustable right center air
vents
b Right center air vent, fixed
c Fixed air vent for defrosting right
side window
d Right side air vent, adjustable
e Thumbwheel for air volume control
for adjustable right side air vent
f Automatic climate control panel
i
When you turn the thumbwheels 5
and a upwards to the first stop, the
fixed center air vents 4 and b and
the adjustable center air vents 6
and 9 are open.
When you turn the thumbwheels com-
pletely upwards, only the adjustable
center air vents
6 and 9 are open.
For draft-free ventilation, move the slid-
ers for the center air vents
6 and 9
to the middle position.
