MANHATTAN LCD
HD8400
Quick Guide
2)
Front
Right Side
Top
Bottom (connectors)
Left Side
12V DC
XLR
Y (G)
Pb (B)
Pr (R)
DVI / HDMI
VGA
S-VIDEO
VIDEO
MOUNT
IN
OUT
HD - SDI
IN
OUT
HD - SDI
12V DC
+
-
UP
DN
MENU
ON/OFF
LCD BRIGHTNESS
-
+
MANHATTAN LCD
8.4” HIGH DEFENITION MONITOR
STATUS I/R
250mm
60mm
175mm
Graphic Key
Casing Screws
Sun Shade
Connectors
1/4-20 Mounting
Ventilation Slits
