Assembly Step 1
- Continued
Check your package contents for these parts. If you are missing any parts, or if any
parts are damaged, please call our toll-free customer service line to order parts.
DO NOT RETURN YOUR SMOKER TO THE RETAILER - CALL US FIRST! 1-800-668-5323
6
LP tank and flavoring hardwood not included.
2505G 3005G 3405G 3405GT 3405GW 3605G 3405BG 3405BGW
1 1 Cabinet Assembly AZ002001 AZ002018 AZ002026 AZ002026 AZ002026 AZ002034 AZ002040 AZ002040
1a 1 Cabinet AZ002002 AZ002019 AZ002027 AZ002027 AZ002027 AZ002035 AZ002041 AZ002041
1b 2 Hinge AZ002003 AZ002003 AZ002003 AZ002003 AZ002003 AZ002003 AZ002003 AZ002003
1c 1 Door Panel AZ002004 AZ002021 AZ002029 AZ002029 AZ002029 AZ002037 AZ002043 AZ002043
1d 2 Wire Rack Track AZ002005 AZ002022 AZ002030 AZ002030 AZ002030 AZ002030 AZ002044 AZ002044
2 Cooking Rack AZ002006 AZ002023 - - - - - - - - - - - - - - - - - -
3 Cooking Rack - - - - - - AZ002031 AZ002031 AZ002031 AZ002031 AZ002045 AZ002045
3 1 Water Pan AZ002007 AZ002024 AZ002024 AZ002024 AZ002024 AZ002024 AZ002024 AZ002024
4 1 Heat Indicator/Nameplate AZ002008 AZ002008 AZ002008 AZ002008 AZ002008 AZ002008 AZ002008 AZ002008
5 1 Air Damper AZ001146 AZ001146 AZ001146 AZ001146 AZ001146 AZ001146 AZ001146 AZ001146
6 1 Door Handle Kit AZ002009 AZ002009 AZ002009 AZ002009 AZ002009 AZ002009 AZ002009 AZ002009
7 1 Wood Box Stand AZ002010 AZ002010 AZ002010 AZ002010 AZ002010 AZ002010 AZ002010 AZ002010
8 1 Wood Chip Box AZ002011 AZ002011 AZ002011 AZ002011 AZ002011 AZ002011 AZ002011 AZ002011
9 1 Wood Chip Box Lid AZ002012 AZ002012 AZ002012 AZ002012 AZ002012 AZ002012 AZ002012 AZ002012
10 1 Burner Assembly AZ002013 AZ002013 AZ002013 AZ002013 AZ002013 AZ002038 AZ002038 AZ002038
11 1 Control Panel Assembly AZ002014 AZ002025 AZ002025 AZ002025 AZ002025 AZ002039 AZ002046 AZ002046
11a 1 Control Knob AZ002015 AZ002015 AZ002015 AZ002015 AZ002015 AZ002015 AZ002015 AZ002015
1 Rotary Ignitor - - - - - - - - - - - - AZ002032 - - - - - - AZ002032
1 Push-Button Ignitor AZ002016 AZ002016 AZ002016 AZ002016 - - - AZ002016 AZ002016 - - -
11c 1 Rotary Igniter Knob - - - - - - - - - - - - AZ002033 - - - - - - AZ002032
12 2 Carry Handle AZ001109 AZ001109 AZ001109 AZ001109 AZ001109 AZ001109 AZ001109 AZ001109
13 3 Standard Leg AZ001103 AZ001103 AZ001103 AZ001103 AZ001103 AZ001103 AZ001103 AZ001103
14 1 Leg with Hole AZ001104 AZ001104 AZ001104 AZ001104 AZ001104 AZ001104 AZ001104 AZ001104
n/a 1 Master Hardware Pack AZ002017 AZ002017 AZ002017 AZ002017 AZ002017 AZ002017 AZ002017 AZ002017
11b
Part Number by Model
2
Item
No.
Description Qty
