• The Integrated Power Module is located in the engine compartment near
the battery. This center contains cartridge fuses, mini-fuses and relays.
Cavity Cartridge
Fuse
Mini Fuse Description
J1 — —
J2 30 Amp Pink Transfer Case Module
J3 — —
J4 25 Amp
Natural Driver Door Node
J5 25 Amp
Natural Passenger Door Node
J6 40 Amp
Green Anti-Lock Brake System (ABS)
Pump Feed/ESP
J7 30 Amp Pink Anti-Lock Brake System (ABS)
Valve Feed/ESP
J8 — —
J9 40 Amp
Green PZEV Sec Motor Feed/Flex Fuel
J10 30 Amp Pink Headlamp Wash Relay/Manifold
Tuning Valve
J11 30 Amp Pink Sway Bar
J12 30 Amp Pink Rear Blower Motor/Radiator Fan
J13 60 Amp
Yellow Ignition Off Draw (IOD) — Main
J14 40 Amp
Green EBL (Rear Window Defogger)
J15 40 Amp
Green Front Blower
J17 40 Amp
Green Starter Solenoid
J18 20 Amp Blue Powertrain Control Module
(PCM) Trans Range
J19 60 Amp
Yellow Radiator Fan
J20 30 Amp Pink Front Wiper LO/HI
J21 20 Amp Blue Front/Rear Washer
J22 — Spare
M1 15 Amp Blue Center High-Mounted Stop Light
(CHMSL)/Switch Stop Lamp
Feed
M2 20 Amp
Yellow Relay Trailer Lighting (Stop)
M3 20 Amp
Yellow Frt/Rear Axle Locker Relay
M4 — —
M5 25 Amp
Natural
Power Inverter - If Equipped
MAINTAINING YOUR VEHICLE
107
