Cavity Cartridge
Fuse
Mini-
Fuse
Description
10 20 Amp
Yellow CCN Power Locks/
Interior Lighting
11 15 Amp
Lt Blue Power Outlet
12 20 Amp
Yellow Ign Run/Acc Inverter
13 20 Amp
Yellow Pwr Run/Acc Outlet
RR/Dome Lamp/
Cigar Lighter
14 10 Amp
Red IOD CCN
15 40 Amp
Green RAD Fan Relay Bat-
tery Feed
16 15 Amp
Lt Blue IGN Run/Acc Dome
Lamp/Sunroof/Rear
Wiper Motor/ACC
Inverter
Cavity Cartridge
Fuse
Mini-
Fuse
Description
17 10 Amp
Red IOD Feed Mod-Wcm
18 40 Amp
Green ASD Relay Contact
PWR Feed
19 20 Amp
Yellow PWR Amp 1 & Amp
2 Feed
20 15 Amp
Lt Blue IOD Feed Radio
21 10 Amp
Red IOD Feed Intrus
Mod/Siren – If
Equipped
22 10 Amp
Red IGN RUN Heat/AC/
Compass Sensor
23 15 Amp
Lt Blue ENG ASD Relay Feed
3
24 15 Amp
Lt Blue Power Sunroof Feed –
If Equipped
7
MAINTAINING YOUR VEHICLE 435
