Jeep 2007 Patriot - Manual (Page 378)

Cavity Cartridge
Fuse
Mini
Fuse
Description
1 Empty Empty
2 15 Amp
Lt. Blue AWD/4WD ECU
Feed
3 10 Amp
Red CHMSL Brake Switch
Feed
4 10 Amp
Red Ignition Switch Feed
5 20 Amp
Yellow Trailer Tow
6 10 Amp
Red IOD Sw/Pwr Mir/
Ocm Steering Cntrl
Sdar/Hands Free
Phone
7 30 Amp
Green IOD Sense1
8 30 Amp
Green IOD Sense2
Cavity Cartridge
Fuse
Mini
Fuse
Description
9 40 Amp
Green Power Seats
10 20 Amp
Yellow CCN Power Locks
11 15 Amp
Lt Blue Power Outlet
12 20 Amp
Yellow Ign Run/Acc Inverter
13 20 Amp
Yellow Pwr run/Acc Outlet
RR
14 10 Amp
Red IOD CCN/ Interior
Lighting
15 40 Amp
Green RAD Fan Relay Bat-
tery Feed
16 15 Amp
Lt. Blue IGN Run/Acc Cigar
Ltr/Sunroof
MAINTAINING YOUR VEHICLE 377
7
