Jeep 2005 Grand Cherokee User Manual
Page 348
Cavity Fuse/Color
Description
32
Micro Relay
TCM Rly (Gasoline Only)
33
Micro Relay
Starter Rly
34
Micro Relay
AC Clutch Rly
35
Micro Relay
Fuel Pump Rly
36
Mini Relay
Cabin Htr 3 Rly (Diesel
Only)
38
Mini Relay
Cabin Htr 2 Rly (Diesel
Only)
39
Mini Relay
HVAC Blower Rly
40
Mini Relay
ASD Rly
Underhood Fuses (Integrated Power Module)
Integrated Power Module
348
MAINTAINING YOUR VEHICLE
