Fotodiox Pro Highkey User Manual
Page 2
1
2
a
ssembling
the
h
ighkey
In an large open area,
gather and sort all of the
contents for an easier
assembly process.
With the screws
removed, insert the
Base Column into the
Wheel Base and secure
screws back on.
Repeat step three with
remaining Wheel Base
and Base Column.
Place the two Base
Plates so that they
look like this.
Insert the two plates
together into the Base
Column with screws
facing down, tighten
lightly.
Connect the two parts
so that it looks like this:
Tighten All Screws.
*View from bottom
*View from bottom
Remove the screws
with included key.
1
2
3
4
5
6
7
The Base
C
ontents
Pro 5x7 Highkey Background Kit Includes
2x Wheel Base
2x Bracket
1x Tool
2x Base Column
4x Softbox Holder
2x Strobe Holder
1x Softbox
1x Case
2x Poles
4x Softbox Lock
1x Bottom
Base Plate
1x Top
Base Plate
