INSTALLATION

ACCESSORIES

21.49in

22.04in

9.80in

1.96in

17.71in

SUSPENSION BY WALL BRACKET

WALL METAL BRACKET TO MOUNT

IN HORIZONTAL POSITION

S

ta

e

12

M

a

16

UK

SM-U12

- Carefully choose speakers place of installation and make sure that the structure can bear box weight.
- Secure the bracket to the wall by using screws in all its fixing holes.
- Place the speaker between bracket arms and secure it through two M10 threaded inserts.

ATTENTION
The STAGEMAXX speaker use only with FBT mount for wall installation.
USE WITH OTHER MOUNTS IS CAPABLE OF RESULTING IN INSTABILITY CAUSING POSSIBLE INJURY.

SUSPENSION BY STATIV ADAPTER

SM-S12

Stativ
