Evolution Engines 58GX - Manual (Page 6)

Part Number Description Part Number Description
EVO30040101 Crankcase EVO30041101 Drive Washer
EVO30040202 Front Bearing EVO30041102 Drive Washer Key
EVO30040204 Packing EVO30041103 Propeller Nut
EVO30040203 Rear Bearing EVO30041104 Propeller Washer
EVO30040301 Rear Cover EVO30041105 Propeller Screw
EVO30040302 Rear Cover Screws Set EVO30041107 Propeller Screws Set
EVO30040303 Rear Cover O-Ring
EVO30040306 Carburetor Flange
EVO30940304 Pressure Nipple
EVO30940305
Pressure Nipple Gasket
EVO30040307 Carb. Flange Gasket
EVO30040401 Cylinder
EVO30040308 Carb. Flange Screws Set
EVO30040402 Cylinder Screws Set
EVO30041301 Reed Valve Case
EVO30040403 Cylinder Nut
EVO30041302 Reed Valve
EVO30040404 Cylinder Gasket
EVO30041303 Reed Valve Screws
EVO30040405 Exhaust Screws Set
EVO30041304 Reed Valve Gasket-Upper
EVO30040406 Exhaust Nut
EVO30041305 Reed Valve Gasket-Bottom
EVO30040407 Exhaust Flange Gasket
EVO30041306 Reed Valve Strap
EVO30040701 Piston
EVO30041307 Carburetor Screws
EVO30040702 Piston Ring
EVO30013312 Electronic Ignition Unit
EVO30040801 Piston Pin
EVO3306 Spark Plug
EVO30040802 Piston Pin Retainer
EVO30941403 Spark Plug Washer
EVO30040901 Connecting Rod
EVO30941404 Locking Screw
EVO30040904 Connecting Rod
Washer EVO30941405 Ignition Sensor Fixing Screws
EVO30041001 Crankshaft
EVO30043225 Carburetor
EVO30010101 Crankcase EVO30011101 Drive Washer
EVO30010202 Front Bearing EVO30011102 Drive Washer Key
EVO30010204 Packing EVO30011103 Propeller Nut
EVO30010203 Rear Bearing EVO30011104 Propeller Washer
EVO30010301 Rear Cover EVO30011105 Propeller Screw
EVO30010302 Rear Cover Screws Set EVO30011107 Propeller Screws Set
EVO30010303 Rear Cover O-Ring
EVO30010306 Carburetor Flange
EVO30940304 Pressure Nipple
EVO30940305
Pressure Nipple Gasket
EVO30010307 Carb. Flange Gasket
EVO30010401 Cylinder
EVO30010308 Carb. Flange Screws Set
EVO30010402 Cylinder Screws Set
EVO30011301 Reed Valve Case
EVO30010403 Cylinder Nut
EVO30011302 Reed Valve
EVO30010404 Cylinder Gasket
EVO30011303 Reed Valve Screws
EVO30010405 Exhaust Screws Set
EVO30011304 Reed Valve Gasket Upper
EVO30010406 Exhaust Nut
EVO30011305 Reed Valve Gasket Bottom
EVO30010407 Exhaust Flange Gasket
EVO30011306 Reed Valve Strap
EVO30010701 Piston
EVO30011307 Carburetor Screws
EVO30010702 Piston Ring
EVO30013312 Electronic Ignition Unit
EVO30010801 Piston Pin
EVO3306 Spark Plug
EVO30010802 Piston Pin Retainer
EVO30941403 Spark Plug Washer
EVO30010901 Connecting Rod
EVO30941404 Locking Screw
EVO30010904 Connecting Rod
Washer EVO30941405 Ignition Sensor Fixing Screws
EVO30011001 Crankshaft
EVO30013225 Carburetor
Part Number Description Part Number Description
45GX 58GX
10 11
