4.0 Operation
Before connecting any components, follow the
safety information in the ETS-Lindgren
Product Information Bulletin included with your
shipment.
To avoid electrical shock, do not make contact
with the power mains conductor when power is
applied through the conductor. When attaching
the Model 3701 Line Probe, always remove
power.
To connect to the line under test:
1. Remove power from the line under test.
2. Pull the plastic safety shroud back to expose the conductive hook.
3. Place the hook around an exposed portion of the power mains
conductor and release the plastic shroud. The spring-loaded shroud
will clamp the contact point.
4. Connect a BNC cable to the coaxial connector on the end of the
Model 3701 Line Probe.
5. Apply power to the power mains.
6. Connect the opposite end of the BNC cable to the input on the
EMI receiver or spectrum analyzer.
Operation | 13
