ETS-Lindgren 3165-01 Absorber Nested Dual-Polarized Dual-Vivaldi Array Antenna - Manual (Page 3)

www.ets-lindgren.com iii
Table of Contents
Notes, Cautions, and Warnings ................................................ v
1.0 Introduction .......................................................................... 7
Model 3165-01 ............................................................................................ 8
Model 3165-02 ............................................................................................ 8
Mounting Options ........................................................................................ 9
3165-01-MG / 3165-02-MG ................................................................. 9
3165-01-SQ / 3165-02-SQ ................................................................ 10
3165-01-RD / 3165-02-RD ................................................................ 10
ETS-Lindgren Product Information Bulletin ............................................... 11
2.0 Maintenance ....................................................................... 13
Annual Calibration .................................................................................... 13
Replacement and Optional Parts .............................................................. 14
Service Procedures .................................................................................. 14
3.0 Specifications ..................................................................... 15
Electrical Specifications ............................................................................ 15
Physical Specifications ............................................................................. 15
3165-01 Series ................................................................................. 15
3165-02 Series ................................................................................. 16
4.0 3165-01 Typical Data.......................................................... 17
3165-01 Typical Gain ................................................................................ 17
3165-01 Typical VSWR ............................................................................. 18
3165-01 Typical Cross-Port Isolation ........................................................ 19
3165-01 Typical Reflectivity ...................................................................... 20
3165-01 Typical E-Plane ........................................................................... 21
3165-01 Typical H-Plane .......................................................................... 22
5.0 3165-02 Typical Data.......................................................... 23
3165-02 Typical Gain ................................................................................ 23
3165-02 Typical VSWR ............................................................................. 24
3165-02 Typical Cross-Port Isolation ........................................................ 25
3165-02 Typical Radiation Patterns .......................................................... 26
3165-02 at 400 MHz and 500MHz..................................................... 26
